BYML510 gas&oil Industrial Italy Burner for 5T boiler Modulating operation Electronic Modulation
Model: BYML510MC
Brand: Baiyan
Fuel: gas and oil
Output Power: 850-5200kw
Control Mode: Mechanical Modulation,gas side progressive two-stage operation, diesel side two-stage
Applicable Power Supply: AC 400v 50Hz
Applicable Boiler: 5T/H
Certificate: ISO
Packaging Details:Neutral/Customized packaging
MOQ: 1pcs
Delivery terms： Sea/Air/Land
Delivery Port: Ningbo Port
Gas and oil burners of stationary boilers are intended for burning gas and fuel oil, as well as for full combustion (in combination with furnace) of fuel by creating homogeneous fuel-air mixture.
Technical Parameters | |||||
Model | BYML450MC | BYML510MC | BYML650MC | BYML750MC | |
Fuel | Natural Gas | Natural Gas | Natural Gas | Natural Gas | |
Control Mode | Electronic Modulation,Progressive two-stage operation. Modulating operation available for both fuels by modulation kit | ||||
Output Power | Kw | 600--4700 | 850--5200 | 700--6500 | 700--7500 |
Flow rate | Sm³/H | 63--497 | 90--550 | 74--688 | 74--794 |
Second Fuel | Light oil | Light oil | Light oil | Light oil | |
Second Fuel Power | Kw | 1000--4700 | 1200--5200 | 1750--6500 | 1750--7500 |
Flow rate | Kg/h | 84--396 | 101--438 | 148--548 | 148--632 |
Motor Power | kw | 9.2±1.5 | 11±1.5 | 15±1.5 | 18.5±1.5 |
Applicable power supply | AC 400v 50Hz | ||||
Safety Protection Level | IP 54 （protection level can be improved according to different requirement) | ||||
NOx | ＜80 | ||||
Applicable boiler | T | 4 | 5 | 6 | 8 |
Dimension | mm | 2050*1520*1000 | 2050*1520*1000 | 2000*1460*1200 | 2000*1460*1200 |
Weight | Kg | 310 | 315 | 330 | 365 |
